PAM, PPM, PWM Modulation & Demodulation Trainer Kit
PAM, PPM, PWM Modulation & Demodulation Trainer Kit
Observations of PAM/PPM/PWM Modulated & Demodulated Waveforms Study of PAM with Sample, Sample & Hold & Flat-top Modulated Outputs Study of PPM & Demodulation using different Sampling Frequencies Study of PWM & Demodulation using different Sampling Frequencies Recovery of Modulating Signals from Demodulator Circuits
Technical Specifications
* In built IC based DC Regulated Power Supply ±12V & 5V/ 300mA
* On board Sine Wave Audio Frequency Signal Generator, Frequency : 1KHz & 2KHz, Amplitude : 10Vpp & 4Vpp Approx.
* On board Square Wave Signal Generator, Frequency : 1KHz & 2KHz, Amplitude : 6Vpp Approx.
* On board Sampling Pulse Generator, Frequency : 8KHz, 16KHz, 32KHz & 64KHz, Amplitude : 5Vpp Approx.
* Demodulation of PAM/PPM/PWM using 4th Order/ Low Pass Filter & AC Amplifier using IC TL074 with adjustable Gain Control
* Glass Epoxy PCB used as front panel & mounted on light weight shock proof plastic cabinet
Size (mm) : 405 x 205 x 85
Power Requirement : 220V AC ±10%, 50Hz
Standard Accessories : Patch Cords & Instruction Manual
Optional Accessories : CRO 20MHz
